PRESS DESIGN
frame design: H-frame, monoblock
PRESS FORCES
total force (nominal): 200 to
TOOL ASSEMBLY DIMENSIONS
distance table - slide max.: 200 mm
distance between columns (H-frame): 320 mm
passline opening (free passage in side columns): 290 mm
EJECTOR (TABLE EJECTOR)
nominal force: 40 to
stroke: 60 mm
ELECTRICAL SPECIFICATIONS
total power consumption: 67 kW
mains voltage: 380 V
mains frequency: 50 Hz
DIMENSIONS / WEIGHTS
space requirements -left/right-: 3410 mm
space requirements -front/back-: 2980 mm
height above floor level: 3320 mm
height under floor level: 150 mm
total weight approx.: 10200 kg
orbital motor defect, replacement required
