PRESS DESIGN
drive system: hydraulic
frame design: H-frame, tie rod
openings in uprights: no
number of suspensions: 1
number of slide actions: 1
table cushion: yes
PRESS FORCES
total force (nominal): 1000 to
PRESS TABLE
table surface (left-right): 2050 mm
table surface (front-back): 1000 mm
height above floor level: 500 mm
SLIDE
slide force: 1000 to
table surface (left-right): 2050 mm
table surface (front-back): 1000 mm
stroke: 1000 mm
SLIDE (HYDR. PRESS)
approximation velocity max.: 500 mm/s
working velocity max.: 62 mm/s
return velocity max.: 470 mm/s
DIE CUSHION (TABLE CUSHION)
cushion force: 200 to
stroke: 80 mm
TOOL ASSEMBLY DIMENSIONS
distance table - slide max.: 1600 mm
ELECTRICAL SPECIFICATIONS
total power consumption: 220 kW
DIMENSIONS / WEIGHTS
space requirements -left/right-: 3200 mm
space requirements -front/back-: 2000 mm
height above floor level: 6500 mm
height under floor level: 1000 mm
total weight approx.: 68000 kg
ATTACHMENTS (PRESSES)
European CE standards: yes
Press is equipped with automatic feeding.
- Cushion Dimensions: 8 circles free Controllable about 1500 wide x 1000mm deep
- CE Compliant
- Accessories:
Lubrication table with automation
Board dimensions: 1300mm long x 800mm wide
Verkauft
